LSS100200 Schneider spaceLYnk KNX logic controller:
LSS100200 Schneider spaceLYnk is the ideal solution for commercial buildings. Thanks to its 2,000 BACnet data points and 31 Modbus devices, spaceLYnk can be effortlessly integrated into complete energy and building management systems.
SpaceLYnk can be used:
■ As a KNX logic controller for the creation of complex building automation solutions
■ As a building automation solution for small and medium-sized buildings with complete control including LRC (lighting and room control (KNX)) and measurement technology (Modbus devices, Smartlink RTU and IP)
■ As a Cross-sector communication for large buildings with complete control via SBO EcoStruXure ™ (BMS from Schneider Electric).
■ As a gateway for communication between different products and protocols.
■ As a data storage device, for analyzing and exporting the data (e.g. as .csv).
■ As a user interface for the display and control of relevant information on PCs and mobile devices.
LSS100200 KNX logic controller Features:
■ Freely programmable logic controller with integrated web server
■ WEB SCADA visualization for PC and mobile devices
■ Marketplace with applications to download and extend the controller’s functionality
■ IFTT support
■ Multi-protocol gateway between KNX (TP / IP) and Modbus RTU / TCP + BACnet IP
■ HTTP / HTTPS / NTP / FTP servers
■ BACnet server (2000 data points)
■ Modbus (31 devices)
■ Login visualization (>50 users)
■ User management tool to define user access and visibility
■ Predefined Modbus templates
■ BACnet certified “BACnet Application Specific Controller (B-ASC)”
■ Integration of IP cameras
■ Simple function block programming
■ Integrated USB port (additional memory, EnOcean & GSM dongles)
■ Freely programmable scheduler
■ IP router
■ Scenes module
■ E-mail and SMS
■ Easy visualization configuration through eConfigure
■ KNX IP Secure compatibility
LSS100200 KNX logic controller Specifications:
Version : white
Art. no : LSS100200
Range of product:KNX
Supply voltage: 24 V DC (not included)
Power consumption: 2 W
Display elements:
– LED indicator 1: Green LED (CPU load)
– LED indicator 2: Green LED (Operation) or Red LED (Reset)
Controls: 1x reset button
Interfaces: 1x KNX TP1, 1x RJ45 Ethernet 10/100 Mbit/s, 1x RS-485 (incl. Polarization resistor 47 kΩ, no termination), 1x RS-232, 1x USB 2.0
Terminals:
– KNX bus: Bus terminal 2 x 0.8 mm
– Power supply: 0.5 mm²–1.5 mm²
– Serial interfaces: 0.5 mm²–1.5 mm²
Operation: -5°C to +45°C
Dimension: 90 x 52 x 58 mm (HxWxD)
Device width: 3 modules = approx. 54 mm
