C2E621201_MB_C1B Schneider KNX thermostat, 21-30 VDC,-5-45 deg C,matt black, Cuadro H
C2E621201_MB_C1B Schneider KNX thermostat, 21-30 VDC,-5-45 deg C,grey, Cuadro H
Comfortable room controller with 4 integrated touch buttons with which all functions from room temperature control to load control (switching, dimming, blind) can be activated.
An FCU controller, a floor heating controller and a ventilation controller are available as HVAC controllers.
The proximity can be triggered by an object (presence detector) and can also be sent, e.g. to trigger another action or for visualization. LEDs show status, the brightness can be defined according to normal and night mode.
ETS device functions:
■ Button volume
■ Proximity function triggered by object
■ Night mode: LEDs light up with reduced brightness
■ Display settings: units, backlight level (normal/standby), delay time
■ Brightness of LED with status ON in normal mode/night mode, selection of the LEDs to be used in night mode
KNX software functions:
2 programming options:
■ Extended settings: Individual configuration
■ Express settings: Calls up a pre-set configuration
Express settings:
■ Dual-surface: Switching on/off, dimming brighter/darker, moving blind up/down, temperature +/-
■ Single-surface: Power on, control mode, operation mode, fan speed, function page, toggeling, Scene
C2E621201_MB_C1B Schneider KNX thermostat Specifications
Bus type : KNX
Main colour tint : Matt black
Range of product : Cuadro H
Product or component type : thermostat
Complementary
Material : PC
Rated current：19 mA
Colour tint : matt black
Screen : Colour touch screen
Product application：Residential
Control type：Proximity function
Power supply：KNX Port: DC 21-30V
approx.24 V/ 19 mA
Measurement accuracy:+/- 1 °C at 25 °C
Installation method：Embedded installation (concealed installation)
Environment
IK grade : IK05
IP protection rating : IP 20
Installation altitude : ≤2000m
Storage temperature ：-20 °C – +60 °C
Operating temperature ：-5 °C – +45 °C
Product dimensions : WxHxD:86x86x29mm
Relative humidity: 10% – 93% no condensation
Package
Package 1 Height : 3.0 cm
Package 1 Width : 8.6 cm
Package 1 Length : 8.6 cm
Package 1 Weight : 179.2 g
Unit Type of Package 1 : PCE
Number of Units in Package 1 : 1
Extended settings:
Switching, dimming, value output, scene control (recall/store a scene), blind, loop operation (stepwise, without steps), RGB lighting (RGB, RGBW), multiple operation in which you can define various functions manually (4 objects – on/off, up/down, recall scene, store scene, percentatge, unsigned value), delay mode, color temperature control. For all function a distinction can be made between short and long operation.
Functions of the room temperature control unit:
■ VRF control
■ Ventilation controller
■ Floor heating controller
■ FCU controller: switching on/off (2-point control), switching PWM (PI control), continuous control (PI control)
General: Scene group, logic function (AND; OR, XOR, threshold comparator, format converter), indication behaviors, locking function
